EYE HOIST HOOK US TYPE

EYE HOIST HOOK US TYPE ()

< Go to HOOKS

/

EYE HOIST HOOK US TYPE

EYE HOIST HOOK is a general purpose hook, suitable for most slinging applications.
Eye Sling Hook fitted with a latch for added security in lifting. Eye allows easy connection to coup links and can be attached to lifting apparatus.

[email protected]

chris-yushanwei

+86-13953206937

Send Message

Products Introduction| Specifications| Related Products| Inquiry

Products Introduction

Specifications

Specifications

WLL(TON)		DIMENSIONS(MM)						WEIGHT
CARBON	ALLOY	D	E	H	K	M	L	KG/PC
1/2	3/4	16.5	19	17	72	16	97	0.21
3/4	1	19	22	19	82	16	110	0.28
1	1-1/2	23	23	21	93.5	17.5	125	0.4
1-1/2	2	28	24	26	103	21	140.5	0.65
2	3	31	27.5	28	119	23	162	0.81
3	5	39	33	37	146	30	201	1.75
5	7	51	40	46.5	186.5	38	256	3.77
7-1/2	11	62	51	57	231.5	46	317	6.8
10	15	73	57	70	260	55	360	9.96
15	22	89	75	76	318	68.5	434	15.33
20	30	90	82	91	360	70	495.5	27.2
